“巴合曼”网络机柜，服务器机柜工艺特点介绍
1、可互换的门铰链
2、钢化玻璃门（钢板门框，5mm单块安全玻璃）或网孔门（钢板）
3、支架 用于安装482.6mm（19英寸）安装角规，深度可以25mm间 隔格式调节
4、侧板 易于拆卸
5、带电缆入口的顶板
6、电缆导入盖板 开口可调，用于电缆入口
7、底座（用于电缆前、后进入）（自选件）或脚轮
8、安装角规 用于满足482.6mm（19英寸）元件的安装
9、背板或后门方便安装和检修
1. Interchangable door hinge
2. Tempered glass door(steel plate door frame, 5 mm single safe glass) or mesh door(steel plate)
3. Frame
Used for installing 482.6 mm(19 in”) installation angle gauge, depth can be up to 25 mm  clearance adjustment.
4. Side plate
Easy to dismantle
5. With cable entrance top plate
6. Cable entrance cover plate
Openings adjustable, used for cable entrance
7. Base(using cable front and rearentrance) (selective) or truckle
8. Install angle gauge
Satisfy 482.6 mm(19 inch) element installation
9. Back plate or back door
  For convenient installation and maintenance

DW-1标准配置
1、底座一个
2、安装纵梁两根
3、安全玻璃门或网孔门一个
4、有侧板
5、后背板
6、安装角规四根（含安装附件）
7、简易包装
1. 1 Base
2. Two installation stringers
3. One safety glass door or mesh door
4. With side plate
5. Rear platt
6. Four installation angle gauge (including installation attachment)
7. Simple packing

柜体颜色Cabinet color
RAL7032(喷塑）RAL7032(plastic spraying)  材料Material
冷轧钢板Cold rolled steel plate
门2.0mm Door 2.0 mm
箱体1.5mm Cabinet 1.5 mm
表面处理Surface treatment
喷塑Plastic spraying
